SEGGER emSSL - Secure Sockets Layer

What is emSSL?

emSSL is a SEGGER software library that enables secure connections across the Internet. emSSL offers both client and server capability.

SSL/TLS is a must-have in nearly every application which is connected to the Internet. Products of the IoT, smart grid or home automation markets benefit from securing their communication.

emSSL offers the possibility to establish a secured connection to any server application from your product. It can be used both target independent in native computer applications, as well as in embedded targets.

Product features

• Highly compact implementation runs effortlessly on single-chip MCUs!
• Easy-to-understand and simple-to-use API reduces getting-started time.

• No complicated configuration needed - connect out of the box in seconds, not days
• Fully tested embOS/IP drop-in configuration for a flying start!
• Integrates with any TCP/IP stack that offers a socket interface
• Secure any open channel (e.g. serial line or wireless link), not only network sockets!
• Supplied with a wide range of pluggable cipher suites for interoperability with popular servers
• Pluggable architecture links only what you need - guaranteed minimal code and data footprint!
• Standard support for TLS 1.0, 1.1, and 1.2
• Leading-edge cipher suites offer robust confidentiality, integrity and authentication
• Diffie-Hellman Ephemeral cipher suites for forward secrecy
• Elliptic curve cipher suites for reduced certificate and key sizes
• Pluggable,"tagged" memory manager keeps confidential data in crypto memory *
• Useful examples provided in source form and as Windows executables for evaluation
• Send emails securely with emSSL **

* Optional feature for secure devices that support cryptographic memory. Please contact SEGGER for device support and availability.

** emSSL delivers the secure connection only. An SMTP client is required to send the email.

Why should I use emSSL?

The emSSL Package

emSSL is a complete package and comes with everything which is needed to secure communication.

It includes all modules which implement the required functionality to use SSL. They are provided in source code, to allow complete control of the code that is used in the product and create transparency to avoid worries about possible back doors or weakness in code, which cannot be checked in precompiled libraries.

emSSL comes with a simple, yet powerful API to make using emSSL in your product as easy as possible.

It also includes sample applications in binary and source code, which demonstrate how and when emSSL can be used in real life scenarios. For a list of included applications, see the chapters below.

Supported Cipher Suites

emSSL includes the most commonly used cipher suites, which allows to connect to nearly every TLS-supporting server.

With emSSL the cipher suites can be added dynamically. When the required cipher suites are known it is possible to create a minimal size configuration by not linking in unused algorithms. This is can be done by the compiler/linker automatically. With the included scan suites application it is possible to find out the required cipher suite(s) to connect to a server.

The following list shows the cipher suites which are available in emSSL.

Performance

emSSL is built for high performance with target independent code. It is completely written in ANSI C and can be used in any embedded application, as well as in PC applications.

Performance Test

The following results show the connection time of a Cortex-M4, running at 200MHz from internal flash memory, using internal RAM.

¹: Results may vary depending on the compiler, compiler settings and memory timings of the microcontroller used.

The times are measured for the negotiation phase, connecting to www.segger.com and www.google.com with the key exchange algorithms (marked in bold).

Cipher Suite is the used cipher suite for this connection which is supported by emSSL and the server.

SSL time is the time required by emSSL to fully agree the session keys for a secure connection — it excludes transmission and reception times over the IP transport which are highly variable.

Included Applications

emSSL includes some sample utilities in source to show how to use emSSL and as precompiled executables. Applications for benchmark and validation tests are part of the package, too.

Example application

This application opens a connection to the SEGGER web site and retrieves the HTML index document over a fully secured connection. As you can see, emSSL makes working with secure sockets a breeze!

int main(int argc, char * const argv[]) {
  SSL_SESSION Session;
  unsigned    Socket;
  int         Status;
  //
  // Kick off networking and start TLS.
  //
  SYS_IP_Init();
  TLS_Init();
  //
  // Open a plain socket to www.segger.com on the default
  // HTTPS port, 443.
  //
  Socket = SYS_IP_Open("www.segger.com", 443);
  if (Socket < 0) {
    printf("Cannot open www.segger.com:443!\n");
    return 100;
  }
  //
  // Upgrade the connection to secure by negotiating a
  // session using TLS.
  //
  SSL_Prepare(&Session, Socket, &TLS_IP_Transport);
  if (SSL_Connect(&Session, 0, "www.segger.com") < 0) {
    printf("Cannot negotiate a secure connection to www.segger.com:443!\n");
    return 100;
  }
  //
  // We have established a secure connection, so ask the server
  // for some data.  This sends an HTTP GET request to retrieve
  // the default index page.
  //
  SSL_SendStr(&Session, "GET /index.html HTTP/1.0\r\n");
  SSL_SendStr(&Session, "Host: www.segger.com\r\n");
  SSL_SendStr(&Session, "\r\n");
  //
  // Now read the response.  We requested HTTP 1.0 which causes
  // the underlying socket to be closed once the reply is complete,
  // so we have no need to decode the headers.
  //
  for (;;) {
    char acBuf[256];
    Status = SSL_Receive(&Session, acBuf, sizeof(acBuf)-1);
    if (Status < 0) {
      break;
    }
    acBuf[Status] = 0;
    printf("%s", acBuf);
  }
  //
  // Close the TLS connection.
  //
  SSL_Disconnect(&Session);
  SYS_IP_Close(Socket);
  //
  // Finish up.
  //
  SSL_Exit();
  SYS_IP_Exit();
  //
  return 0;
}

FAQ

Glossary

The following table explains the abbrevations used in the cipher suite names.
