 Dear Customer,

Modern chips require an ever-increasing degree of customer and device-
specific configuration. Security plays a particularly important role here, as
more and more devices are connected to the Internet. Unfortunately,
there is still no industry standard for providing chip security and
The options for this vary from semiconductor manufacturer to
semiconductor manufacturer and even from microcontroller to
microcontroller. In addition, microcontrollers are constantly evolving and
therefore require a flexible tool.

Masterpiece of Software Development: Device Provisioner
With the Device Provisioner, SEGGER offers a new tool for its Flasher
programming devices as well as for its debug and trace probes J-Link and
The Device Provisioner is a command line tool that allows users to
customize the configuration of their microcontrollers with extreme
flexibility. The tool supports conditioning and programming (including
special areas), downloading certificates, assigning serial numbers, locking
and unlocking as well as security activation and configuration of
In addition, users can enable or disable the debug interface, set fuses,
program option bytes and flash, and anything else that needs to be pre-
configured for development or production.
"The Device Provisioner is a masterpiece of software development," says
Rolf Segger, founder of SEGGER. "The tool allows any conceivable
configuration of the microcontroller hardware. It has a built-in C compiler
and grants full access to all interfaces and functions offered by J-Link and
Flasher, including the fully user-programmable interface coprocessors to
cover existing and future protocols."

The most universal Tool for Embedded Systems
All these aspects make Device Provisioner without exaggeration the most
universal tool in the history of embedded systems. The developers of SEGGER have really outdone themselves with the development of this tool.

The Device Provisioner executes commands from a script written in C,
which can be written by SEGGER, the semiconductor manufacturer or the
user himself.
And best of all: The Device Provisioner is part of the software package
for the J-Link and Flasher product family.
Script files can be executed on J-Links and Flashers when they are
connected to a host PC. Flasher programming devices can also run the
script files in standalone mode.
Script files may be distributed in source code or, to protect intellectual
property, in pre-compiled form.
With SEGGER's production programming devices and debug probes, users
are already equipped today for the challenges of tomorrow.
For more information, please visit Device Provisioner.

Systematic Test Design using CTE
The Classification Tree Editor (CTE) from RAZORCAT is a graphical editor
for the systematic and easy-to-understand creation of test cases in a
graphical format. The CTE is used for the conversion of a (functional)
specification into a series of error-sensitive and low-redundancy test case
In principle, the CTE can be used in all test phases and programming
languages, for any IT application and for embedded, mobile and web
The following sections outline the core functions of the CTE. Your
comments and questions about our product are always welcome. Please
feel free to contact me.

The basic Idea of the Classification Tree Method
The Classification Tree Method enables a simple test design for different
areas of software development. This requires the following two steps:
  • Identify the test-relevant aspects (classifications) and the respective corresponding values (classes).

  • As a rule, this is implemented on the basis of the (functional) specification of the software to be tested. These aspects represent the input and output data of the test object.

  • Combining the various classes from all classifications in test cases.

  • Creating test case specifications with the graphical editor

  • The Classification Tree Editor (CTE) is used to design  classification trees and create test case specifications in an intuitive way.

  • Describing the tree elements, as well as the test-relevant aspects and their recursive partitioning into equivalence classes to build the classification tree.

  • Setting values on tree elements and combining tree classes to specify inputs and expected results in a combination table. Textcases can then be created based on this.

  • The result is a comprehensible test case specification: The description text of selected tree elements and their values are used to generate the test case specification.
The test case specifications can be exported as *xml, *x/sx, *,txt, *.sug,
*.png, *.jpg.

Key Features and Advantages for you
  • Creation of error-sensitive and low-redundancy test cases
  • Creating, importing and exporting classification trees

  • Definition of dependency rules between the test aspects

  • Automated generation of test case specifications

  • Automatic validation checks

  • Statistical data

  • Customizable auto-layout
The CTE has functions for more detailed test case specifications and the
subdivision of a tree into sub-trees. In addition, the CTE offers easy
navigation through sub-trees and elements as well as simplified handling
using drag & drop and short keys.
Advantages for you
  • Systematic and easy-to-understand creation of test cases using a graphical editor.

  • Partially automated generation of test case specifications.

  • Export of test data for further use by other tools, e.g. TESSY.

  • Available as an integrated version in TESSY or as a standalone version for Windows 7/8/10/11 (64bit)

Learn more about Tracealyzer 4.9
As you already know from last Newsletter, Percepio AB, the leading
provider of continuous observability solutions for embedded edge
systems, has recently announced the availability of Tracealyzer v4.9.
The focus for this release has been to improve the user experience when
installing and running Tracealyzer on a Linux host computer. Installation
has been greatly simplified by a new standalone installation package that
includes everything needed to run Tracealyzer. On most Linux
distributions, a new user can now be up and running in a few minutes.
"Providing first class Linux support is of key importance to us at Percepio.
Many software developers prefer Linux. We have a growing developer
community that has contributed with a lot of feedback and testimonials
over the years. We are very grateful for their support and want to give
back to the Linux community with this Tracealyzer release, where the
main objective is improved user experience for Linux users," says Johan
Kraft, founder and CTO at Percepio.
The user experience and performance on Linux has been improved
significantly. Several Linux-related bugs and Gul issues have been fixed,
the application starts up faster, and traces load faster.

Aktualisierung für andere RTOS
Tracealyzer Version 4.9 ist ab sofort bei Percepio und bei uns erhältlich. Upgrades sind für aktuelle Benutzer mit einem aktiven Abonnement oder Wartungsvertrag kostenlos. Eine zeitlich begrenzte Testversion der Software kann hier heruntergeladen werden.
The TraceRecorder support for Eclipse ThreadX and SAFERTOS has also
been updated in the new version, to improve recorder integration and
support the most recent RTOS features. SAFERTOS support is provided via
WITTENSTEIN high integrity systems.
Tracealyzer 4.9 also brings improved support for LynxOS-178, the
standards-based RTOS for safety-critical real-time applications from Lynx
Software Technologies, such as the ability to record process data in the
TraceRecorder library and group threads by process in the trace view.
LynxOS-178 support is provided via Lynx Software Technologies.
Tracealyzer version 4.9 is available immediately from Percepio and from
us. Upgrades are free for current users with an active subscription or
maintenance contract. A time-limited evaluation copy of the software can
be downloaded here.


I wish you a good and healthy summertime
For the upcoming summer break, I wish you leisure and time for yourself
and your family and time away from your daily work.
Come back from your vacation with creative new ideas!

Yours Sincerely
Marian A. Wosnitza
PS. I will be happy to write to you again on September 1st.
